Image (pixels)

640 (H)*480 (v)pixels

Light Source

Aiming: 625 nm LED; illumination:4000K LED

Depth of Field

45° horizontal, 34° vertical

Scan Angle

Left and right:± 55 °, Front and rear:± 55 °, Rotate:360 °

Image Sensor

CMOS

Print Contrast

≥20%

Visual Indicator

Green LED light, Buzzer, Motor Vibration

Scan Distance

20-200mm @ EAN 13mil PCS=100%
5-170mm @ QR 20mil PCS=100%

Power Parameter

Input Voltage: 5VDC±5%, Working corrent: 400mA

Dimension / Weight

173*66*94(mm), 202g(With mini adapter)

Drop Durability

1.6M, IP42

Scan Mode

Handhand (Manual) / Handfree (Automatic)

Frame Rate

300 scans / seconds

Scan accuracy

≥4mil@ Code39

Transmission Range

2.4G:100m; Bluetooth HID/BLE/SPP: 40m(in open air)

Work frequency

2.400GHz-2.480GHz ISM frequency

Case Material

ABS+PC, TPU

Firmware Update

Computer online upgrade

Paired Mode

one to one, or one to more (Optional)

Battery Parameters

Battery Capacity: 2000mAh, Charge Mode:Wire charging, Charge time:5h,
Working time:12h (continuous scanning)

Barcode Decode

1D: UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN,
Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93, Interleaved 2 of 5 (ITF),
Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),etc.
2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode, Dotcode, GS1 DataBar stack, etc.

Environmental parameters

Operating Temperature:-10°~+ 50°
Working Humidity: 5% to 95% relative humidity, non-condensing
Storage Temperature:-20°~+60° Electrostatic protection:±8 kV(Direct discharge)
Ambient brightness:0~100,000Lux
