Print Head / Ink

Type

Permanent (Replaceable)

Number of Nozzles

Black: 640 nozzles (Optional Colour: 1 152 nozzles)

Ink Bottles / Cartridges

GI-70 (Pigment Black)
Optional: CL-741, CL741XL

Printing Resolution

600 (horizontal)^*1 x 1 200 (vertical) dpi

Document (ESAT/Simplex)

13.0 images per minute (black) / 6.8 images per minute (colour)

Document (ESAT/Duplex)

4.8 images per minute (black) / 2.8 images per minute (colour)

Document (FPOT Ready / Simplex)

9s (black) / 14s (colour)

Printable Width

203.2mm (20.32 cm)
Borderless: 216mm (21.59 cm)

Printable Area

Borderless Printing^*3

–

Bordered Printing

#10 Envelope/DL Envelope:
Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mm

LTR / LGL:
Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mm

Others:
Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm

Bordered Auto 2-Sided Printing

Top / Bottom margin: 5 mm,
Left / Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm)

Support Media

Rear Tray

Plain Paper (64-105 g/m² (gsm))
High Resolution Paper (HR-101N)
Envelope

Cassette

Plain Paper (64-105 g/m² (gsm))

Paper Size

Rear Tray

A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Card Size (91×55 mm)

[Custom size]
width 55 – 215.9 mm, length 89 – 676 mm

Cassette

A4, A5, B5, LTR

[Custom size]
width 148.0 – 215.9 mm, length 210 – 297 mm

Paper Handling (Number)

Rear Tray

Plain Paper (A4, 64 g/m² (gsm)) = 100
High Resolution Paper (HR-101N) = 80

Cassette

Plain Paper (A4, 64-105 g/m² (gsm)) = 250

Support Media for Auto 2-sided printing

Type

Plain Paper

Size

A4, A5, B5, LTR

Paper Weight

Rear Tray

Plain Paper: 64-105 g/m² (gsm)

Cassette

Plain Paper: 64-105 g/m² (gsm)

Ink End Sensor

Electrode type and dot count type combined
Optional Colour Cartridge; Dot count

Print Head Alignment

Auto/Manual

Protocol

TCP/IP, SNMP

Wired LAN

Network Type

IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T)

Data Rate

10M/100Mbps (Auto switchable)

Wireless

Network Type

IEEE802.11n / IEEE802.11g / IEEE802.11b

Frequency Band

2.4GHz

Channel^*4

1-13

Range

Indoor 50m (Depends on the transmission speed and conditions)

Security

WEP64/128bit
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Direct Connection (Wireless LAN)

Available

Canon Print Service
for Android

Available

PIXMA Cloud Link
(from smartphone/tablet)

Available

Canon PRINT

Available

Windows 10 / 8.1 / 7 SP1
(Operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)

Language

32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese

Interface

Hi-Speed USB 2.0

PictBridge (Wireless / Wired LAN)

Available

Operating Environment^*6

Temperature

5 – 35°C

Humidity

10 – 90% RH (no dew condensation)

Recommended Environment^*7

Temperature

15 – 30°C

Humidity

10 – 80% RH (no dew condensation)

Storage Environment

Temperature

0 – 40°C

Humidity

5 – 95% RH (no dew condensation)

Quiet Mode

Available

Acoustic Noise (PC Print)

Plain Paper (A4, B/W)^*8

Approx. 52.0dB(A)

Power

AC 100-240V, 50/60Hz

Power Consumption

OFF

Approx. 0.3 W

Standby (scanning lamp is off)
USB connection to PC

Approx. 0.8W

Standby (all ports connected, scanning lamp is off)
[EU only – for ErP Lot 26 regulation]

Approx. 1.6W

Time to enter Standby mode
[EU only – for ErP Lot 26 regulation]

Approx. 1min 29sec.

Printing^*9
USB connection to PC

Approx. 13W

Typical Electricity Consumption (TEC)^*10

0.1 kWh

Environment

Regulation

RoHS (EU, China), WEEE (EU)

Duty Cycle

Up to 15,000 pages/month

Dimension (WxDxH)

Factory Configuration

Approx. 403 x 369 x 166 mm

Output/ADF trays extended

Approx. 403 x 695 x 356 mm

Weight

Approx. 6.0kg
