Rugtek-RP80-V1
Discover the future of receipt printing with Rugtek’s Linerless printer/Receipt Printer. Designed to redefine efficiency, this printer boasts a 72mm print width, accommodating a range of printing needs. With an impressive speed of up to 350mm/sec, it ensures swift and seamless printing, optimizing your workflow. The printer’s exceptional resolution of 203dpi (8dot/mm) guarantees sharp and precise output for your receipts. Featuring a default USB interface, it effortlessly connects to your devices, while the optional USB, Serial, and Ethernet interfaces offer expanded connectivity possibilities. Experience a new era of versatile and high-speed printing with Rugtek’s Linerless Printer/Receipt Printer, where innovation meets performance for unmatched results.
Features
• Linerless/Receipt Printer
• Print Width: 72mm
• Printing Speed: 350mm(Max)/sec
• Resolution: 203dpi (8dot/mm)
• Interface: Default USB + Serial + Ethernet
Specification
Printer Type | Receipt printer |
Print Method | Direct Thermal |
Print Width | 48mm & 72mm |
Paper Width | 57.5mm & 80mm/203dpi |
Paper Roll Size (W x D) | 57.5 – 80mm |
Label thickness Roll dia | 0.06~0.15mm 80mm max/ Easy Paper Loading |
Paper Type | Continuous / marked |
Print Head Life | 160km |
Print Font/Barcode | Support any Languages |
Flash | 4MB |
RAM | 8MB |
Color | Black |
Cutter | Auto-Cutter with Selectable Full or Partial Cut or Tear off |
Cutter lifetime | 1500000 cuts |
Media Type | Receipt paper/Multiplex Ticketing (Black Mark Sensor) / Linerless Printing |
Power Source | 24V/2.5A |
Interface/Connectivity | Default USB+SERIAL+Ethernet |
Driver Support | Windows / Linux / OPOS |
Printing Command | ESC/Windows Driver/OPOS |
Barcode & Graphic Support/Other Features | Big Gear Long Life, Durable Performance, Wall hanging option, |
Flash light when receive order, Voice reminding (Optional), NFC Function (Optional) | |
Barcode Fonts and Graphics Support | 1D: UPC-A, UPC-E, EAN-8, EAN-13, CODABAR, Code 39, Code 93, ITF, CODABAR |
2D support | PDF 417, QRCODE, GS1 |
Font Support | Font A, Font B |
Character set | 95 Alphanumeric, 13 types International Characters |
Graphics printing | Bitmap Image Downloading and Direct Bitmap Image Print |
Power Adapter | External Power Adapter 100-240VAC, 50- 60Hz, |
24V ± 5% DC, average current 2A | |
Sensors | Paper End Sensor, Top Cover Open Sensor |
Printing Dimension (LxWxH) | 200*146*140mm |
Working temperature: 0~40°C | |
Environment | Storage temperature: -20~70 |
Working humidity: 20~85%; | |
Storage temperature: 5~95% |
